Specifications of Pallet Racks

Pallet rack is a common type of various types of racks. It is favored by many users for its simple structure, convenient transportation, convenient installation and simple use. With the widespread use of pallet racks, there is now a unified specification parameter standard among industries. The following describes the pallet specifications of heavy-duty pallet racks.

Pallet rack specification parameters:

1 Length (L): The length refers to the horizontal span of the shelf, which can also be divided into inner diameter, outer diameter and center distance

Inner diameter - the length from one column to the outside of another column

Outer diameter - the total length of the main frame

Center distance - the length from the midpoint of one column to the midpoint of another column

2 Width (W) or depth (d): Refers to the total longitudinal distance of the column. For details, see the schematic diagram of the width of the main and auxiliary frames.

3 Height (H): Refers to the total height of the shelf. The details are as follows:, refer to the height in the schematic diagram of the main and auxiliary frames

4 layers: refers to the total number of layers of shelf beams

5 Bearing capacity: refers to the average weight that each layer of the shelf can bear
